Item:Chargery POWER DB8 2S-8S Li-Po Li-Fe balance Balancer

Chargery POWER DB8 2S-8S Li-Po Li-Fe balance Balancer

Item condition:--
Ended14 Nov, 200913:50:50 AEDST
Quantity:
More than 10 available
Please enter a quantity of $quantity$ or less
Please enter a quantity of 1
Price:US $55.99
Approximately AU $61.23
Postage:FREE postage Expedited Int'l Flat Rate PostageSee more services

Country:
Postcode:
Quantity:
(available quantity 100)
Service and other details:
Service
Estimated delivery*
Price
Expedited Int'l Flat Rate Postage
varies
Free
*The estimated delivery time is based on the seller's handling time, the shipping service selected, and the payment method selected. Sellers are not responsible for postage service transit times. Transit times may vary, particularly during peak periods.

 See discounts

 |  See all details
Estimated delivery time varies for items sent from an international location
Payments:
Returns:
3 day money back, buyer pays return shipping | Read details

A reserve price is the minimum price the seller will accept. This price is hidden from bidders. To win, a bidder must have the highest bid and have met or exceeded the reserve price.


Seller info
goodlucksell ( 41080) Member is a PowerSeller
98.8% Positive feedback
Other item info
Item number:290359947720
Item location:HK, Hong Kong
Posts to:Worldwide
 SharePrintReport item
 Description Postage and payments
Visit my eBay store

Chargery Power DB8 2S-8S Li-Po Li-Fe balance Balancer

Descripion:

  • DB8 is a intelligent balancer designed especially for 2S - 8S LiPo/LiFe battery pack, it has a microprocessor to detect and balance each cell voltage of the 2 to 8 cells in series.
  • You can balance the battery while charge, discharge or at stand alone mode. you still can take DB8 as cell meter to check your battery status.
  • Nixie display indicator display each cell voltage, battery pack voltage, difference of cell voltage and the balance state of the battery pack.
  • Cooperating with charger, the built-in software can detect the cell voltage in charging. When any cell voltage reaches 4.22V,  it will cut off the charger to prevent the battery overcharged.
  • Besides independent balance mode, you can connect any LiPo or LiFe charger to the input lead first, then connect the DB8 to the balance connector on your pack, finally connect the output leads to the discharge wire of the pack.  so your pack is charging at up to 10A and balancing simultaneously.

Feature:

  1. Automatically detect and display battery balance status for any 2 to 8 cells pack
  2. Imbalance voltage warning and balancing
  3. Audio alarm for over voltage
  4. Audio alarm for under voltage
  5. Nixie display indicator display each cell in balancing
  6. Automatically cut-off the charging circuit while charge
  7. Reversely polarity protection on input, output and balance connector
  8. Balance 1 or 2 - 4 battery packs simultaneously
  9. With Special Connector Conversion Board(CCB-9KT) to fit all kinds of XH type battery connectors

2 working mode:

  1. Stand-alone balancing
  2. Balancing while charge or discharge, need to be connected to 8S or below professional charger - such as iMax B8.

Input/Output Specifications:

  1. Input Voltage/Current: DC 35V, 10 A MAX.
  2. Output Voltage: 35V MAX.
  3. Output Current: 10A MAX.
  4. Current drain for balancing : 300mA/cell
  5. Balance accuracy : <10mV

General Specifications:

  1. Operating Temperature:                  0~40⊥
  2. Storage Temperature:                    -20~85⊥
  3. Operating Relative Humidity:         5~95%RH

Mechanical Characteristics:

  1. Dimension: 115*68*15(mm, L*W*H) or 4.52"*2.67"*0.59"
  2. Case Material : Al alloy
  3. Balances Connector : JST XH 9PIN
  4. weight :   150g

Item included:

  • 1 unit of Chargery Power DB8 8S Li-Po/Li-Fe Intelligent Battery Balancer
  • 1 pc. CEH-9 conversion wire
  • 1 pc. CW24 input power lead
  • 1 pc. CW3 4mm banana with battery MALE connector
  • 1 pc. of Chargery Power CCB-9KT-XH balance connector conversion board which capable to balance or charge with multiple combination of Chargery Power, Kokam, Graupner, Align and Dualsky batteries (allow different voltage and capacity of batteries) as below:
  • 4*2S / 2*3S + 2S / 2*4S / 2*4S + 3S / 5S + 3S / 6S + 2S
