| Specifications
|
| Platform |
Intel® Centrino® processor technology
- Intel® Core™2 Duo Processor T5750
- Intel® PRO/Wireless 4965AGN
- Intel® 965GM
|
| Operating System |
Genuine Windows Vista® Business
with XP Pro downgrade |
| Display |
12.1-inch WXGA TFT, 1280 x 800 pixels |
| Modular Bay Device |
Dual Layer DVD Super Multi Writer |
| Memory |
2GB DDR2 667MHz |
| Hard Disk |
160GB |
| Battery |
Up to 4 hrs1 (6-cell Li-ion 5200mAh)
|
| Weight |
1.7kg |
| Detailed Specifications |
| Hard Disk Drive |
SATA-150 (5400rpm) |
| Graphics |
Integrated Intel® Graphics Media Accelerator X3100 with Intel® Clear Video Technology5 and DVMT4 4.0 delivers low-power, high-performance 2D/3D graphics with Shader Model 3.0, video and display capabilities at a max. shared
memory of 384MB
|
| Audio |
RealTek ALC262 Sound Chip with stereo speakers Audio-in: (line-in / microphone) Audio-out: (line-out / headphone)
|
| 3.5G Ready6 |
Upgrade now to embeded 3.5G(HSDPA) WWAN connectivity of up to 7.2 Mbps7 downlink. - Also Supports EDGE7 and GPRS7 |
| Communication
|
1.3 Mega Pixel camera, Optional 56K V.92 modem6, built-in 10/100/10002 Mbps Marvell 88E8055, Intel® PRO/Wireless 4965AGN network connection and optional Bluetooth® v2.0
|
| User Interface |
Keyboard 86-keys, 19mm pitch, 2.5mm key stroke
Touch Pad with two mouse buttons
|
| Card Slots |
1 x ExpressCard™ 34mm slot, Memory card slot (SD, MS, xD and MSPRO) |
| Connector Interface |
USB 2.0 x 3, VGA (external display), S-Video out (TV-out), Memory Card, RJ45 (LAN), Optional RJ11 (modem)6, Audio-in, Audio-out, Power Adapter DC-in
|
| Security3 |
User and supervisor BIOS password, Anti-theft Lock Slot |
| Dimensions |
300mm (W) x 223mm (D) x 37mm (H) |
| Bundled Accessories6 |
| AC Adapter |
Input AC 100~240V, Output DC 20V/90W Adapter |
1. Results obtained from BAPCO MobileMark2005(Reader Workload) performed on systems with maximum battery life settings under
laboratory testing environment. Actual battery life will vary based on screen brightness, sound volume settings, running applications,
connected peripherals, power management settings, battery conditioning, and other customer preferences in real life situation.
2. This term does not represent actual data rate of 1000/100/10Mbps and simply indicates compliance with IEEE 802.3, IEEE
802.3u and IEEE 802.3ab standards. Actual maximum data rate depends on network configurations, cable conditions as well as
connected devices.
3. BIOS Lock needs a supervisor/user password to access BIOS setup. BIOS settings can be configured to prompt for password
at every first bootup or all bootup sequences. Anti-theft Lock Slot allows the use of a lock to physically secure the Notebook.
4. Dynamic Video Memory Technology (DVMT) dynamically responds to application requirement and efficiently allocates the proper
amount of memory (max. 384MB) for optimal graphics and system performance. The memory size available to the Operating System
will be less than the size of installed memory module.
5. Intel® Clear Video Technology is a combination of video processing hardware and software technologies that delivers
enhanced high-definition video playback, sharper images, precise color control and advanced support for a wide range of digital
displays interfaces, including High-Definition Multimedia Interface(HDMI).
6. Please check actual bundling / Specification with country local distributor.
7. Subjected to network and SIM capabiltiies. Data rates refers to download or upload speed which are also dependent on network
capabilities and conditions.
It is natural for all thin-film transistor (TFT) liquid crystal displays (LCD) to show a small number of missing or discolored
dots. These are commonly known as non-conforming pixels. This is a technology limitation of TFT LCD and does not represent
a defect. Fujitsu warranty does not cover limitations in technology such as non-conforming pixels.
Specifications reflected above are engineering and hardware specifications. They do not represent actual usage or operating
dimensions, sizes, performances and weights as these are dependent on factors such as operating temperature, type of operating
system and application used, connected devices and accessories as well as hardware configurations of the notebook. Please
check the compatibility of 3rd party accessories before purchase. Ambient temperature: 5° to 35°C / 41 to 95°F (operating),
-15° to 60°C / 5 to 140°F (non-operating). Relative humidity: 20% to 85% RH (operating), 8% to 85% RH (non-operating). Please
note that 1GB is equivalent to 1,073,741,824 bytes.
|
