Power Supply:. 100-240 V AC, 50 Hz
Power Consumption: 12 W
Signal Readout System : Optical non-contact
Signal System : PAL/Auto
Video Output : 1.0 Vp-p, 75 Ohms,
Negative sync., Pin jack x 1
S-Video Output : (Y) 1.0 Vp-p, 75 Ohms,
Negative sync., Mini DIN 4-pin x 1
Component Signal Output : (Y) 1.0 Vp-p, 75 Ohms,
Negative sync., Pin jack x 1,
(PB)/(PR) 0.7 Vp-p, 75 Ohms, pin jack x 2
Audio Output
Digital Audio Optical: -22.5 dBm x 1
Digital Audio Coaxial : 0.5 Vp-p, 75 Ohms,
Pin jack x 1
Audio Ouput (2-channnel): 2.0 V (RMS), 470 Ohms,
Pin jack x 1
Frequency Response :
4 Hz-22 kHz (48 kHz),
4 Hz-44 kHz (96 kHz)
Harmonic Distortion : 0.01 % (1 kHz)
Audio Dynamic Range : 96 dB
Signal-to-Noise Ratio: 100 dB
Wow and Flutter : Below threshold of measurability
Dimensions (W x H x D) :
435 x 81 x 359 mm
Weight : 3.7 kg
|
